24VAC 250W IP68 Waterproof Power Transformer for Swimming Pool Lighting,CE UL marked
24VAC 250W IP68 Waterproof Power Transformer for Swimming Pool Lighting,CE UL marked
Type: Outdoor IP68 Waterproof Transformer
Shape: Square
Input Voltage: AC 110V / 240V
MPN: Does Not Apply
Output Voltage: AC24Vac
Brand: Unbranded OEM
Product Details:
Place of Origin: shenzhen
Brand Name: OEM Anenerge
Certification: CE UL GS TUV PSE KC ETL
Model Number: RYPO-24Vdc-250W
Payment & Shipping Terms:
Minimum Order Quantity: 1~10pcs
Price: 1~3usd/pcs
Packaging Details: Neutral white box packaging
Delivery Time: 3~5days
Payment Terms: L/C, D/P, T/T, Western Union,Paypal
Supply Ability: 100000pcs/month
M.N. | Size (mm) | Output Specifications | ||
Output Voltage (V) | Output Current (A) | Output Power (W) | ||
AC24v | 10.4a | 250 | ||
Input Specifications | Input Voltage | AC120 | ||
Input Frequency | 50~60Hz | |||
Input Current | 0.45A | |||
Input Surge Current | 40A@AC100V | |||
Dielectric Strength | Withstanding Voltage | 2000V AC 60S | ||
Insulation Resistance | 2000V AC 60S | |||
Output Specifications | Voltage Accuracy | ≤5% | ||
Ripple & Noise | ≤1%*Vout (mVp-p) | |||
Voltage Regulation | ±0.5% max | |||
Load Regulation | ±0.5% max | |||
Over Voltage Protection | 150% min | |||
MTBF | >50,000 Hrs | |||
Operating Temperature | 0~40°C | |||
Storage Temperature | -20~85°C | |||
Operating Relative Humidity | 5-95% RH | |||
Over Currrent Protection | 150% min | |||
Shot-cut Protection | Auto Recover | |||
Certificate | CE, ROHS, CB, UL, CUL, FCC, CCC, | |||
Products warranty | 2 years |
Quick Details:
- Output: 24Vac
- Power: 250Watt
- Installation: desk-top (or as per client’s requests)
- Color: white or black
- Socket: without
- Material: PC
- LED indication: yes
- Safety standard: EN61558-2-16/EN60950/EN61347-2-13/UL1310/EN60050
- Protection: short circuit/overload/over voltage/over temperature
- No load power consumption: less than 0.1W
- Certifications: UL, ETL, FCC, CE, GS, BS, SAA, CCC
- Standards: UL/CUL, GS, BS, CE, SAA, C-Tick, CB, PSE, CCC, KC
- Energy efficiency level VI
- 2 years warranty
- MTBF: 50000 hours
- Plugs available: US/EU/UK/AU/KC/PSE/3C
- RoHS compliant: yes
- Working environment: 0°C-40°C, 5%-90%RH
- Storage environment: -20°C-85°C, 5%-95%RH
I. It is of waterproof IP68 Transformer , breaking the traditional aluminum housing practices, plastic shell, good security, water resistance, water resistance than aluminum safety and better.
2. Safety :. ETL / UL, ETL / GS, CE, CB, SAA, UL, TUV certification.
3. Waterproof grade: IP68
4. Inputs and output line will be equipped with waterproof as well and Outputs will be to your choice.
5. Waterproof wire for choice: HO7 /HO5 rubber line, SJTW , SPT-1W ,SPT-2W ,SPT-1 SPT-2, HO3VDE line.,suitable for light control, supporting remote control, remote control transmitter. light control
6. Usage:waterproof outdoor lights, garden lights, buried lights, underwater lights, waterproof lighting, LED lights, fountain lights, Christmas lamps. Pumps, motors, finger lights.
7, Available for BBQ grill power supply
