12V 5A 10A 60W 100W power supplies with UL marked power adapter for LED strips
12V 5A 10A 60W 100W power supplies with UL marked power adapter for LED strips
| Product Electric Parameters | ||||
| Input specification | Input voltage | AC100V—240V | ||
| Input frequency | 50-60Hz | |||
| Input surge | 20A@120VAC 40A@230VAC | |||
| Output specification | Output voltage can be adjusted | ±10% | ||
| Start-up time | <1S(input230V Io=100%) | |||
| keep time | >20mS (input230V,Io=100%) | |||
| Voltage regulation | (Full load) <0.5% | |||
| Protection function | Overload protection | 105% – 150% rated power,
automatic recovery |
||
| Over-voltage protection | 105% – 150% of the rated voltage | |||
| Insulation intensity | Input—output | 1500VAC/1min | ||
| Input—ground | 1500VAC/1min | |||
| Input—ground | 500VAC/1min | |||
| Safety standards | According with GB4943, UL60950-1,EN60950-1 standards. | |||
| E M C standards | According with GB9254, EN55022 class A EN61347-2-13:2008 standards | |||
| Environmental | working temperature | – 20 ° ~ 60 ° c / 20% ~ 90% RH (no frost) | ||
| Storage temperature | – 40 ° ~ 85 ° c / 10% ~ 95% RH (no frost) | |||
| height above sea level | <2000M | |||
| Cooling method | Cooling method | Natural cooling air convection | ||
| Product Type Table | ||||
| Product model | output specification | ripple, noise | efficiency | |
| S1205000 | 12V | 5A | about 35mV | >86% |
